Construction | |
| Construction Chassis | Heavy-Duty Steel Chassis |
| Mounting Configuration | Wall VESA 100, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 12.1 " |
| Brightness | 600 Cd/m2 |
| Contrast Ratio | 700~1 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | Intel Atom E3845 |
Memory | |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Ethernet | |
| Controller Type | Intel i210-IT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 3 |
| USB 2.0 | 3 |
Connectors | |
| Connectors | DB9, HDMI, 2xRJ45, DC Input |
Software | |
| Operating System Compatibility | Windows 7, Windows 8, Linux OS |
Dimensions and weight | |
| Width | 311 mm |
| Height | 272 mm |
| Depth | 58 mm |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
