Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Type | Fanless |
CPU | |
| Processor Installed | AMD Ryzen V3C18I |
| Socket | CPU onboard |
Chipset | |
| Chipset | SoC |
Memory | |
| Socket Type | 2xSODIMM 262-pin |
| ECC | Yes |
| Default on Board Memory | 8 GB |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Ethernet | |
| Controller Type | Intel i226-LM |
| Total Ethernet | 6 |
| 2,5 Gbit/s | 4 |
| 10 Gbit/s | 2 |
Interfaces | |
| USB Total | 4 |
| USB 2.0 | 1 |
Extension Slots | |
| M.2 | 1 |
Connectors | |
| Connectors | 4xRJ45 Ethernet, 4xUSB, DC Input, 2xSFP, Console Port Mini USB |
Software | |
| Operating System Compatibility | Linux OS, Windows IoT Enterprise 10, Windows 10, Windows 11 |
Dimensions and weight | |
| Width | 45 mm |
| Height | 160 mm |
| Depth | 130 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
