Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Desktop, Wall |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Core i3 |
| Max CPU frequency | 2.2 GHz |
Chipset | |
| Chipset | Intel QM67 |
Memory | |
| Form-factor | DDR3 |
| ECC | No |
| Default on Board Memory | 2 GB |
| Maximum Memory | 10 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel 82583V 10/100/1000 Mbps, Intel 82579 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | 802.11b/g/n |
Interfaces | |
| COM Total | 8 |
| RS-232 | 6 |
| RS-422/485 | 2 |
| USB Total | 6 |
| USB 2.0 | 4 |
| USB v3.x | 2 |
Industrial Interfaces | |
| CAN Port | 1 |
Storage Cage | |
| Number Of Cage External | 2 |
| 2.5" Cage Intenal | 2 |
Extension Slots | |
| Total | 2 |
| Mini-PCIe/Mini Card | 2 |
Connectors | |
| Connectors | DB9, 4xDB9, DB15 VGA, HDMI, 4xRJ45, 2xRJ45 Ethernet, 6xUSB, Mic In, Line Out, DC Input, DC input (terminal block), CAN (terminal block) |
System Power Input | |
| Input Voltage DC | 9...36 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 90 W |
Software | |
| Operating System Compatibility | Windows XP Embedded, Windows Embedded Standard 7 |
Dimensions and weight | |
| Width | 310 mm |
| Height | 62 mm |
| Depth | 200 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
| Vibration | MIL-STD-810F 514.5C-2 |
| Shock | 5G. half sine. 11ms |
Standards and Certifications | |
| Certifications | CE, FCC |
