Construction | |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
CPU | |
| Processor Installed | Intel Core i5-6500TE |
| CPU Support Type | Core i7, Core i5 |
| Max CPU frequency | 3.3 GHz |
Chipset | |
| Chipset | Intel H110 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Default on Board Memory | 4 GB |
| Maximum Memory | 32 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | 802.11b/g/n |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB v3.x | 4 |
Extension Slots | |
| PCI Express x1 | 2 |
| PCI | 1 |
Connectors | |
| Connectors | DB15 VGA, HDMI, 2xRJ45 Ethernet, Mic In, Line Out |
System Power Input | |
| Input Voltage DC | 9...36 V |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Standard 8, Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 132.6 mm |
| Height | 255.2 mm |
| Depth | 190 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration |
| Vibration And Shock | IEC 60068-2-6 |
