Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall |
| Type | Fan |
CPU | |
| СPU Generation/Family | Alder Lake |
| Socket | LGA1700 |
Chipset | |
| Chipset | Intel R680E |
Memory | |
| Socket Type | 2xSODIMM |
| ECC | No |
| Default on Board Memory | 16 GB |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel UHD Graphics |
Ethernet | |
| Controller Type | Intel i225LM, Intel i225V |
| Total Ethernet | 2 |
| 2,5 Gbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| COM Total | 6 |
| RS-232 | 4 |
| RS-232/422/485 | 2 |
| USB Total | 8 |
Digital Input-Output | |
| Channels of DIO | 12 |
Storage Cage | |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 2 |
| PCI Express x8 | 2 |
| M.2 | 2 |
Connectors | |
| Connectors | 6xDB9, HDMI, 2xRJ45, 8xUSB, DC input (terminal block), DB15 GPIO, 4-pin DC input |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 180 W |
Software | |
| Operating System Compatibility | Linux OS, Windows IoT Enterprise 10, Windows 11 |
Dimensions and weight | |
| Width | 137.9 mm |
| Height | 230.6 mm |
| Depth | 255.4 mm |
Operating Conditions | |
| Vibration | MIL-STD-810G 514.6C-1 (with SSD) |
| Shock | Half-sine wave shock 5G. 11ms. 100 shocks per axis (SSD) |
Standards and Certifications | |
| Certifications | CE, FCC |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration |
