tGW-734i

Name: tGW-734i
Brand: ICP DAS
SKU: 08328300
Availability: InStock

ICP DAS

Ціна за запитом

Tiny Modbus/TCP to RTU/ASCII Gateway with PoE and 2 Isolated RS-232 and 1 Isolated 485 Ports (RoHS)

Специфікація

Specification

Ethernet
Total Ethernet	1
10/100 Mbit/s	1
Interfaces
COM Total	3
RS-232	2
RS-485	1
Isolation of COM Ports	3 kV (RS-232), 3 kV (RS-485)
Supported Protocols
Industrial Protocols	Modbus TCP server, Modbus TCP client, Modbus RTU slave, Modbus RTU master, Modbus ASCII slave, Modbus ASCII master
System Power Input
Input Voltage DC	12...48 V
Power over Ethernet (PoE)	PoE, IEEE 802.3af
Operating Conditions
Operating Temperature	-25...75 °C
Construction
Construction Chassis	Plastic Chassis
Mounting Configuration	DIN-Rail mount
Dimensions and weight
Width	52 mm
Depth	27 mm
Height	95 mm
Connectors
Connectors	Screw Terminal
