Construction | |
| Mounting Configuration | Panel |
| Protection Level of Front Side (Panel) | IP65 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 19 " |
| Maximum resolution | 1280x1024 Dots |
| Brightness | 250 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | Intel Core i5-5350U |
| Max CPU frequency | 2.9 GHz |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 3 |
| USB 2.0 | 3 |
Installed drive | |
| Drive Type | SSD |
| 1st Storage Capacity | 128 GB |
Connectors | |
| Connectors | 3xDB9, DVI-I, RJ45 Ethernet, 3xUSB, Mic In, Line Out |
System Power Input | |
| Input Voltage DC | 9...36 V |
| Input Voltage AC | 115...230 V |
Standards and Certifications | |
| EMI | EN 55022 |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11 |
| Safety | EN 60950-1 |
