System Architecture | |
| Form Factor | Thin Mini-ITX |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Celeron N3160 |
| Socket | CPU onboard |
| Max CPU frequency | 2.24 GHz |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 2xSODIMM |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel Gen.8 Graphics Engine |
| Interfaces | DisplayPort, HDMI, VGA |
Ethernet | |
| Controller Type | Realtek 8111E |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 4 |
| RS-232/422/485 | 2 |
| USB Total | 6 |
| USB 2.0 | 2 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC662 |
Drive interfaces | |
| mSATA | 1 |
| MicroSD | 1 |
Extension Slots | |
| Total | 2 |
| PCI Express x1 | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 2xSATA 3, 2xUSB 2.0, 4x10-pin RS-232, 6-pin KB/MS, 2x10-pin RS-232/422/485 |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
