TP-5120/NP

TP-5120/NP

ICP DAS
Ціна за запитом
12.1" (800 x 600) resistive touch panel monitor with RS-232 or USB interface Accessories: VGA cable, RS-232 cable, USB cable, Mounting clamps and screws, w/o Power supply

Specification

Construction

Construction ChassisPlastic Chassis
Mounting ConfigurationPanel, Wall VESA 100, Wall VESA 75
Protection Level of Front Side (Panel)IP65

Display

Display TypeLCD TFT
Diagonal12.1 "
Maximum resolution800x600 Dots
Brightness400 Cd/m2
Contrast Ratio500~1
Input InterfaceVGA

Touch Screen

Touch Screen TypeResistive
InterfaceRS-232, USB

System Power Input

Input Voltage DC12...48 V
Power Consumption13 W

Operating Conditions

Operating Temperature-20...70 °C

Dimensions and weight

Width323 mm
Height254 mm
Depth65 mm

Files

Documentation

📄 Datasheet_tp-5120
