Specification
Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Ethernet |
| 10/100 Mbit/s | 1 |
Supported Protocols |
| Industrial Protocols | Modbus TCP server |
Digital Input |
| Total channels of digital input | 2 |
| Type | Wet contact |
| Level of Logic "0" | 0~4 V |
| Level of Logic "1" | 10~50 V |
| Sink/Source | Wet: Sink/Source |
| Isolation of Digital Input | 3750 V |
Digital Output |
| Total channels of digital output | 2 |
| Type | PhotoMos relay |
| Relay (Form A) | 2 |
| Contact rating of relay (Form A) | 1A@60V DC |
Connectors |
| Connectors | Screw Terminal |
Additional Functions |
| Watchdog timer type | Hardware, Software |
System Power Input |
| Input Voltage DC | 12...48 V |
| Power over Ethernet (PoE) | PoE |
Dimensions and weight |
| Width | 52 mm |
| Depth | 27 mm |
| Height | 98 mm |
Operating Conditions |
| Operating Temperature | -25...75 °C |
Files
Documentation
📄 tET-P6,tET-C4,tET-A4,tET-P2C2,tET-P2A2,tET-P2POR2,tET-P2R2,tPET-P6,tPET-C4,tPET-A4,tPET-P2C2,tPET-P2A2,tPET-P2POR2,tPET-P2R2_dat
📄 datasheet datasheet-tet-c4_cr
📄 User Manual PETL / tET / tPET
