Ethernet |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
| Type 10/100 Mbit/s | 2xRJ-45 |
Supported Protocols |
| Managment Protocols | SMTP, SNMPv1/v2c/v3, HTTP, Telnet, TCP, DHCP, DNS |
| Security Protocols | HTTPS, SSH, ICMP |
Expansion Module |
| Quantity of Slots | 18 |
| Supported Module | CSM-200, TCF-142-RM, CSM-400 |
LED / Controls |
| Setup of Operation Mode | Telnet, Console Port, Web-interface |
Connectors |
| Connectors | Console Port USB |
System Power Input |
| Input Voltage AC | 36...53 V |
| Power Supply Reserve input Voltage AC | 110...240 V |
Operating Conditions |
| Operating Temperature | -20...55 °C |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
Dimensions and weight |
| Width | 440 mm |
| Depth | 88 mm |
| Height | 260 mm |
Standards and Certifications |
| Certifications | CE, WEEE, FCC |
| EMI | EN 55022 Class A, FCC Part 15 Subpart B Class A |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11 |
| Safety | UL 60950-1, EN 60950-1 |
