Construction | |
| Construction Chassis | ABS plastic chassis |
| Mounting Configuration | Wall VESA 75, Arm |
| Protection Level of Front Side (Panel) | IP55 |
| Protection Level of Chassis | IP55 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 10.4 " |
| Maximum resolution | 1024x768 Dots |
| Aspect Ratio | 4:3 |
| Brightness | 500 Cd/m2 |
| Contrast Ratio | 1000~1 |
| Input Interface | Smart Display Port |
Touch Screen | |
| Touch Screen Type | Resistive |
LED / Controls | |
| LED | 1xOn/Off LED |
| Controls | On/Off, 1xReset, Function Keys |
Additional Functions | |
| Sensors | Auto-Dimming, K-type thermalcouple temperature sensor |
Connectors | |
| Connectors | USB type A, 1x36-pin -Smart Display Port |
System Power Input | |
| Input Voltage DC | 12...12 V |
| Power Consumption | 11 W |
Operating Conditions | |
| Operating Temperature | -30...70 °C |
Dimensions and weight | |
| Width | 303 mm |
| Height | 225.3 mm |
| Depth | 35 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
| MIL-STD-810 | MIL-STD-810G Test Method 516.6 Shock |
| Safety | UL/cUL, CB |
