Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall |
| Protection Level of Chassis | IP42 |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Celeron 3855U |
| Socket | CPU onboard |
| Max CPU frequency | 1.6 GHz |
Memory | |
| Default on Board Memory | 4 GB |
| Assembly | Removable |
Ethernet | |
| Controller Type | Intel i210AT 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 5 |
| USB 2.0 | 1 |
| USB v3.x | 4 |
Industrial Interfaces | |
| CAN Port | 2 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage External | 1 |
Extension Slots | |
| Total | 3 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 2 |
| SIM Card slots | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 3xDB9, DB15 VGA, 4xUSB, DC Input, 3xM12, DB9 DIO |
System Power Input | |
| Input Voltage DC | 9...30 V |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows 10 |
Dimensions and weight | |
| Width | 225 mm |
| Height | 63.91 mm |
| Depth | 148 mm |
Operating Conditions | |
| Operating Temperature | -25...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| Marine grade | DNV |
| Rolling Stock | EN 50155, EN 45545, EN 50121-3-2 |
| Vehicle | E-Mark |
