Construction |
| Construction Chassis | Metal Chassis, Aluminium Chassis |
| Mounting Configuration | Built-in, Desktop, Wall |
| Type | Fanless |
CPU |
| СPU Generation/Family | Alder Lake, Raptor Lake |
| Socket | LGA1700 |
| CPU Support Type | Core i3, Core i5, Core i7 |
Chipset |
| Chipset | Intel Q670E |
Memory |
| Form-factor | DDR5 |
| Socket Type | 1xSODIMM |
| ECC | No |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic |
| Graphic Controller | Integrated in CPU, Intel UHD Graphics |
Ethernet |
| Controller Type | Intel i225V |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB v3.x | 4 |
Drive interfaces |
| SATA 3 | 2 |
| M.2 | 1 |
| mSATA | 1 |
Storage Cage |
| 2.5" Cage Intenal | 2 |
Extension Slots |
| Total | 3 |
| M.2 | 2 |
| M.2 Form Factor | 2280 M, 2242 M, 3052 B, 3042 B |
| Mini-PCIe/Mini Card | 1 |
| SIM Card slots | Yes, 1, Nano SIM |
Connectors |
| Connectors | 2xHDMI, 2xRJ45 Ethernet, 4xUSB, SIM Card Slot, 2xDisplayPort, DC input (terminal block), 4xDB9 |
System Power Input |
| Input Voltage DC | 24...24 V |
Power Supply |
| Supported Types of Power Supply | External power adapter AC/DC |
Software |
| Operating System Compatibility | Windows 10 |
Dimensions and weight |
| Width | 200.2 mm |
| Height | 81 mm |
| Depth | 270 mm |
Operating Conditions |
| Operating Temperature | -5...55 °C |
| Humidity | 10-95% |
| Vibration | Random: 0.5Grms@5~500 Hz. IEC60068-2-64; 2Grms@5~500 Hz. IEC60068-2-64; Sinusoidal: 0.5Grms@5~500 Hz. IEC60068-2-6; 2Grms@5~500 Hz. IEC60068-2-6 |
| Shock | SSD: 20G. half sine. 11ms. IEC60068-2-27; M.2: 50G. half sine. 11ms. IEC60068-2-27 |
Standards and Certifications |
| Certifications | CE, IEC 61000-6-2, IEC 61000-6-4, FCC Class A |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27, IEC 60068-2-64 |
