Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall |
Analog Input |
| Total channels of analog input | 6 |
| Number of Bits | 16 Bit |
| Voltage range | +/-500 mV, +/-1 V, +/-5 V, +/-10 V |
| Current range | 0...20 mA, 4...20 mA, -20...+20 mA |
| Sampling rate | 10 Hz |
Analog Output |
| Channels of analog input | 2 |
| DAC Bit Rate | 12 Bit |
| Voltage range | 0...5 V, 0...10 V, +/-5 V, +/-10 V |
| Current range | 0...20 mA, 4...20 mA |
Digital Input |
| Total channels of digital input | 2 |
| Type | Dry contact, Wet contact |
| Level of Logic "0" | 3.5~30 V |
| Level of Logic "1" | 0~1 V |
| Counter capacity | 16 Bit |
| Max frequency | 0.05 kHz |
| Counter | 50Hz, 16 bit |
Digital Output |
| Total channels of digital output | 2 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 5~50 V |
| Max. load current | 700 mA |
Supported Protocols |
| Industrial Protocols | MQTT client |
System Power Input |
| Input Voltage DC | 12...48 V |
| Power over Ethernet (PoE) | PoE |
Dimensions and weight |
| Width | 92 mm |
| Depth | 42 mm |
| Height | 120 mm |
Operating Conditions |
| Operating Temperature | -25...75 °C |
Standards and Certifications |
| EMS | IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5 |
