Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | DIN-Rail mount |
CPU | |
| Processor Installed | ARM Cortex A8 |
| Max CPU frequency | 1 GHz |
Memory | |
| Form-factor | DDR3 |
| Default on Board Memory | 0.5 GB |
Ethernet | |
| 10/100 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232/422/485 | 4 |
| USB 2.0 | 1 |
Drive interfaces | |
| SD Slots | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | Console Port RS-232 (RJ-45) |
System Power Input | |
| Input Voltage DC | 9...48 V |
| Power Consumption | 6 W |
Software | |
| Operating System Installed | Linux OS |
Dimensions and weight | |
| Width | 57 mm |
| Height | 136 mm |
| Depth | 100 mm |
Operating Conditions | |
| Operating Temperature | -10...60 °C |
Standards and Certifications | |
| EMI | FCC Part 15 Subpart B Class A, CISPR 32 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 55024, EN 61000-6-2, EN 61000-6-4, EN 55032 |
| Safety | UL 60950-1, EN 60950-1, IEC 60950-1 |
