Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
| Type | Fanless |
CPU |
| Processor Installed | ARM Cortex A8 |
| Socket | CPU onboard |
| Max CPU frequency | 1 GHz |
Memory |
| Form-factor | DDR3 |
| ECC | No |
| Default on Board Memory | 0.25 GB |
| Maximum Memory | 0.5 GB |
| Assembly | Fixed on Board |
Ethernet |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
Interfaces |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 1 |
| USB 2.0 | 1 |
Drive interfaces |
| MicroSD | 1 |
Extension Slots |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions |
| Watchdog timer type | Software |
Connectors |
| Connectors | 2xRJ45 Ethernet, SIM Card Slot, DC input (terminal block), 2xCOM (terminal block), 2xSMA, MicroSD card slot, USB type A, Console port RS-232 (4-pin) |
System Power Input |
| Input Voltage DC | 12...24 V |
| Power Consumption | 5.4 W |
Software |
| Operating System Installed | Linux OS |
Dimensions and weight |
| Width | 27 mm |
| Height | 128 mm |
| Depth | 101 mm |
Operating Conditions |
| Operating Temperature | -10...60 °C |
| Vibration | 2 Grms. random wave. 5-500 Hz. 1 hr per axis |
| Shock | 20 G. half sine wave. 30 ms |
Standards and Certifications |
| Certifications | CE, WEEE, FCC |
| EMI | FCC Part 15 Subpart B Class A, EN 55022 Class B |
| EMS | EN 55024-4-2, EN 55024-4-3, EN 55024-4-4 |
| Safety | CCC, UL 60950-1, EN 60950-1 |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-64 |
