Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | DIN-Rail mount |
| Protection Level of Chassis | IP30 |
CPU |
| Processor Installed | ARM Cortex A7 |
| Max CPU frequency | 1 GHz |
Memory |
| Form-factor | DDR3L |
| Default on Board Memory | 2 GB |
Ethernet |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 1 |
| USB 2.0 | 1 |
Industrial Interfaces |
| CAN Port | 1 |
Drive interfaces |
| MicroSD | 1 |
Connectors |
| Connectors | Console port RS-232 (4-pin) |
System Power Input |
| Input Voltage DC | 12...48 V |
| Power Consumption | 12 W |
Software |
| Operating System Installed | Linux OS |
Dimensions and weight |
| Width | 27 mm |
| Height | 141 mm |
| Depth | 120 mm |
Operating Conditions |
| Operating Temperature | -40...85 °C |
Standards and Certifications |
| EMI | FCC Part 15 Subpart B Class A, CISPR 32 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-6-2, EN 61000-6-4, EN 55032, EN 55035 |
| Explosion safety | IECEx, ATEX Zone 2 Group II, UL/cUL Class I Division 2 |
| Oil And Gas | Class I Div.2 Groups A, B, C, D, ATEX Zone 2 Ex nC IIC |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-64 |
