Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
| Protection Level of Chassis | IP30 |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Elkhart Lake |
| Processor Installed | Atom x6413E |
| Socket | FCBGA1493 |
| Max CPU frequency | 3 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | Soldered |
| Default on Board Memory | 8 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Intel UHD Graphics |
| Interfaces | HDMI |
Ethernet | |
| Controller Type | Intel i210-IT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| USB Total | 2 |
| USB v3.x | 2 |
Installed drive | |
| Storage Form-Factor | eMMC |
| 1st Storage Capacity | 64 GB |
Extension Slots | |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | HDMI, 2xUSB, 2xRJ45 |
System Power Input | |
| Input Voltage DC | 10...30 V |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Windows 10, Windows 11, Ubuntu 20.04 |
Dimensions and weight | |
| Width | 33.5 mm |
| Height | 70 mm |
| Depth | 100 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
| Humidity | 5-85% |
Standards and Certifications | |
| Certifications | CE/FCC |
| Safety | CCC, UL, BSMI |
