Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in, Desktop, Wall, DIN-Rail mount, Wall VESA 75 |
| Protection Level of Chassis | IP40 |
| Type | Fanless |
CPU |
| Processor Installed | Intel Core i5-6300U |
| Socket | CPU onboard |
| Max CPU frequency | 3 GHz |
Memory |
| Form-factor | DDR4 |
| Socket Type | Soldered |
| Default on Board Memory | 8 GB |
| Assembly | Fixed on Board |
Graphic |
| Graphic Controller | Intel HD Graphics 620 |
Ethernet |
| Controller Type | Intel i210-IT, Intel i219-IT |
| Total Ethernet | 4 |
| 10/100/1000 Mbit/s | 4 |
Interfaces |
| COM Total | 4 |
| RS-232/422/485 | 4 |
| USB Total | 4 |
| USB v3.x | 4 |
Audio |
| Audio Controller | Intel HD Audio |
Drive interfaces |
| RAID Levels | 1 |
| mSATA | 1 |
Storage Cage |
| Number Of Cage External | 2 |
| 2.5" Cage Intenal | 2 |
Extension Slots |
| Total | 4 |
| Mini-PCIe/Mini Card | 4 |
Additional Functions |
| Watchdog timer type | Software |
Connectors |
| Connectors | 4xDB9, HDMI, 4xRJ45 Ethernet, 4xUSB, Line Out, Display Port, DC input (terminal block) |
System Power Input |
| Input Voltage DC | 10...36 V |
| Power Consumption | 95.2 W |
Software |
| Operating System Compatibility | Windows 7, Linux OS, Windows 10 |
Dimensions and weight |
| Width | 200 mm |
| Height | 70 mm |
| Depth | 140 mm |
Operating Conditions |
| Operating Temperature | -20...60 °C |
Standards and Certifications |
| Certifications | CE, FCC |
| Safety | CCC, UL, BSMI |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-64 |
