Construction | |
| Mounting Configuration | Built-in, Desktop, Wall |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Celeron J1900 |
| Max CPU frequency | 2.42 GHz |
Chipset | |
| Chipset | Intel Atom SoC |
Memory | |
| Form-factor | DDR3L |
| ECC | No |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB 2.0 | 3 |
| USB v3.x | 1 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| PCI Express x1 | 2 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
| PCI | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 4xDB9, DB15 VGA, HDMI, 2xRJ45 Ethernet, 4xUSB, Line Out, 4-pin DC input |
System Power Input | |
| Input Voltage DC | 10...36 V |
| Power Consumption | 24 W |
Software | |
| Operating System Compatibility | Windows 7, Windows Embedded Standard 7, Windows 8, Windows 10 |
Dimensions and weight | |
| Width | 145 mm |
| Height | 177 mm |
| Depth | 238 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
| Vibration | 3Grms. 5...500Hz.(SSD) |
| Shock | 50G. half sine. 11ms(SSD) |
Standards and Certifications | |
| Certifications | CE, FCC |
| Safety | CCC, UL, BSMI |
