Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in, Wall, DIN-Rail mount |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Atom E3815 |
| Max CPU frequency | 1.46 GHz |
Chipset | |
| Chipset | Intel Atom SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | Soldered |
| Default on Board Memory | 2 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Realtek 8111E |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 3 |
| RS-485 | 1 |
| RS-232/422/485 | 2 |
| USB Total | 1 |
| USB v3.x | 1 |
Extension Slots | |
| Total | 3 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 2 |
| SIM Card slots | Yes |
Antenna characteristics | |
| Cellular interfaces | 3G |
Additional Functions | |
| GPS | GPS |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 2xDB9, HDMI, 2xRJ45, 1xUSB, DC input (terminal block), GPIO (terminal block), Terminal block |
System Power Input | |
| Input Voltage DC | 10...30 V |
| Power Consumption | 20 W |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 125 mm |
| Height | 50 mm |
| Depth | 125 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
| Vibration | Operating. IEC60068-2-6. 2 Grms. random. 5 ~ 500 Hz. 1hr/axis (M.2) |
| Shock | Operating. IEC 60068-2-27. 50G. half sine. 11 ms |
Standards and Certifications | |
| Certifications | CE, FCC |
| Safety | CB, UL |
