Specification
Interfaces | |
| USB Total | 4 |
System Power Input | |
| Input Voltage DC | 12...40 V |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Dimensions and weight | |
| Width | 80 mm |
| Depth | 130 mm |
| Height | 35 mm |
Standards and Certifications | |
| EMI | FCC Part 15 Subpart B Class A, CISPR 32 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 55024, EN 55032 |
| Safety | UL 508 |
