Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Digital Input | |
| Total channels of digital input | 10 |
| Type | Dry contact, Wet contact |
| Level of Logic "0" | 0~4 V |
| Level of Logic "1" | 10~50 V |
| Sink/Source | Dry: Source, Wet: Sink/Source |
| Counter capacity | 16 Bit |
| Max frequency | 0.5 kHz |
Digital Output | |
| Total channels of digital output | 8 |
| Contact rating of relay (Form A) | 5A@250V AC, 5A@30V DC |
| Relay (Form C) | 8 |
| Contact rating of relay (Form C) | 2A@30V DC, 0.25A@250V AC |
Connectors | |
| Connectors | Screw Terminal |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
Dimensions and weight | |
| Width | 31 mm |
| Depth | 129 mm |
| Height | 147 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
Standards and Certifications | |
| EMS | IEC 61000-4-2 |
