Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Desktop |
Expansion Module | |
| io_type | multifunctional |
Analog Input | |
| Total channels of analog input | 4 |
| Number of Bits | 14 Bit |
| Voltage range | +/-1 V, +/-1.25 V, +/-2.5 V, +/-5 V, +/-10 V, +/-4 V, +/-20 V |
| Sampling rate | 48 Hz |
| Single-Ended channels | 8 |
| Differential channels | 4 |
Analog Output | |
| Channels of analog input | 2 |
| DAC Bit Rate | 12 Bit |
| Voltage range | 0...5 V |
Digital Input | |
| Total channels of digital input | 8 |
| Type | Wet contact |
| Level of Logic "0" | 0~0.8 V |
| Level of Logic "1" | 2~5 V |
| Sink/Source | Sink |
| Number of channels | 1 |
| Counter capacity | 32 Bit |
| Max frequency | 5 kHz |
Digital Output | |
| Total channels of digital output | 8 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 0~5 V |
| Max. load current | 4 mA |
Connectors | |
| Connectors | Screw Terminal |
System Power Input | |
| Input Voltage DC | 5...5 V |
Dimensions and weight | |
| Width | 132 mm |
| Depth | 32 mm |
| Height | 80 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
