Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Desktop |
Expansion Module | |
| io_type | di_do |
Digital Input | |
| Total channels of digital input | 16 |
| Type | Wet contact |
| Level of Logic "0" | 0~2 V |
| Level of Logic "1" | 5~50 V |
| Sink/Source | Sink |
| Isolation of Digital Input | 2500 V |
| Number of channels | 2 |
| Counter capacity | 32 Bit |
| Max frequency | 16 kHz |
Digital Output | |
| Total channels of digital output | 16 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 5~40 V |
| Max. load current | 100 mA |
Connectors | |
| Connectors | Screw Terminal |
System Power Input | |
| Input Voltage DC | 5...5 V |
Dimensions and weight | |
| Width | 132 mm |
| Depth | 32 mm |
| Height | 80 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
