Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Desktop, DIN-Rail mount |
Digital Input | |
| Total channels of digital input | 8 |
| Level of Logic "0" | 0~1.5 V |
| Level of Logic "1" | 5~24 V |
| Isolation of Digital Input | 2500 V |
| Number of channels | 2 |
| Counter capacity | 32 Bit |
| Max frequency | 1 kHz |
Digital Output | |
| Total channels of digital output | 8 |
| Relay (Form A) | 4 |
| Contact rating of relay (Form A) | 05A@120V AC, 2A@30V DC |
| Relay (Form C) | 4 |
| Contact rating of relay (Form C) | 2A@30V DC, 0.5A@120V AC |
Connectors | |
| Connectors | 20-pin box header |
System Power Input | |
| Input Voltage DC | 5...5 V |
Dimensions and weight | |
| Width | 42 mm |
| Depth | 157 mm |
| Height | 114 mm |
Operating Conditions | |
| Operating Temperature | 0...55 °C |
