Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Built-in, Desktop, Wall |
| Protection Level of Chassis | IP40 |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Skylake |
| Socket | LGA1151 |
Chipset | |
| Chipset | Intel Q170 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Ethernet | |
| Total Ethernet | 8 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
| mSATA | 1 |
Storage Cage | |
| Number Of Cage External | 4 |
| 2.5" Cage External | 4 |
Extension Slots | |
| Total | 4 |
| Mini-PCIe/Mini Card | 4 |
| SIM Card slots | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 2xDB9, DVI, DB15 VGA, HDMI, 4xUSB, Mic In, Line Out, DC Input, 8xM12, DIO (terminal block) |
System Power Input | |
| Input Voltage DC | 9...36 V |
| Power Consumption | 218 W |
Software | |
| Operating System Compatibility | Windows 7, Windows 8, Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 280 mm |
| Height | 99.2 mm |
| Depth | 210.5 mm |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
| Vibration | 3 Grms w/ SSD (5 ~ 500 Hz. X/Y/Z direction; random) |
Standards and Certifications | |
| Certifications | CE, FCC |
| Rolling Stock | EN 50155 |
| Vehicle | E-Mark |
