Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall, Wall VESA 100 |
| Protection Level of Chassis | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 21.5 " |
| Maximum resolution | 1920x1080 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 250 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Whiskey Lake |
| Processor Installed | Intel Core i5-8365U |
| Max CPU frequency | 4.1 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xDIMM |
| Default on Board Memory | 4 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 2 |
| SFP 100/1000 Mbit Ports | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB v3.x | 4 |
Drive interfaces | |
| M.2 | 1 |
Storage Cage | |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| PCI Express x4 | 1 |
| M.2 | 2 |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 2xDB9, HDMI, 2xRJ45, 4xUSB, Mic In, Line Out, DC Input |
System Power Input | |
| Input Voltage DC | 12...24 V |
| Power Consumption | 40 W |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 84 W |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10, Ubuntu 18.04 LTS |
Dimensions and weight | |
| Width | 517.64 mm |
| Height | 313.51 mm |
| Depth | 43.5 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
| Vibration | 0.5G |
| Shock | 5G peak acceleration (11 msec. duration) |
Standards and Certifications | |
| Certifications | CE, FCC |
| Safety | CCC, CB, UL, BSMI |
