Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in, Desktop, Wall, DIN-Rail mount |
| Type | Fanless |
CPU |
| Processor Installed | Intel Atom E3845 |
| Max CPU frequency | 1.91 GHz |
Chipset |
| Chipset | Intel Atom SoC |
Memory |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic |
| Graphic Controller | Integrated in CPU |
Ethernet |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB 2.0 | 2 |
| USB v3.x | 1 |
Audio |
| Audio Controller | Intel HD Audio |
Drive interfaces |
| mSATA | 1 |
| SD Slots | 1 |
Extension Slots |
| Total | 2 |
| Mini-PCIe/Mini Card | 2 |
| SIM Card slots | 1, Multi-SIM |
Antenna characteristics |
| Cellular interfaces | 3G |
Additional Functions |
| Watchdog timer type | Software |
Connectors |
| Connectors | HDMI, 2xRJ45 Ethernet, 3xUSB, DC Input, SMA Female, 2xDB9 Male, 10-pin connector |
System Power Input |
| Input Voltage DC | 9...36 V |
| Power Consumption | 18 W |
Power Supply |
| Type of Power Supply | External power adapter AC/DC |
Software |
| Operating System Compatibility | Windows Embedded Standard 7, Linux OS |
Dimensions and weight |
| Width | 150 mm |
| Height | 48.8 mm |
| Depth | 120.2 mm |
Operating Conditions |
| Operating Temperature | -40...70 °C |
| Vibration | 5 Grms. 5 Hz to 500 Hz. 1 hr/axis w/ mSATA. SD |
| Shock | 100 g/11ms ±X. ±Y. ±Z. 3 shocks each axis w/ mSATA. SD |
Standards and Certifications |
| EMI | EN 61000-3-2, EN 61000-3-3, EN 55022 Class A |
| EMS | IEC 61000-6-2, EN 55024, EN 61000-6-4 |
| Safety | CCC, UL 60950-1, UL 508, EN 60950-1, CSA C22.2 No. 60950-1-03 |
