Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Type | Fanless |
CPU |
| Processor Installed | Intel Celeron 1047UE |
| Max CPU frequency | 1.4 GHz |
Memory |
| Form-factor | DDR3 |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic |
| Graphic Controller | Integrated in CPU |
Ethernet |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces |
| RS-232/422/485 | 4 |
| USB Total | 4 |
| USB 2.0 | 4 |
Digital Input |
| Isolation DIO | Yes |
Drive interfaces |
| mSATA | 1 |
| CFast Slots | 1 |
Extension Slots |
| Mini-PCIe/Mini Card | 2 |
| SIM Card slots | 2 |
Additional Functions |
| Watchdog timer type | Software |
Connectors |
| Connectors | 4xDB9, DVI-I, HDMI, 2xRJ45 Ethernet, 4xUSB, DC input (terminal block), DIO (terminal block) |
System Power Input |
| Input Voltage DC | 9...36 V |
| Power Consumption | 34 W |
Software |
| Operating System Compatibility | Windows Embedded Standard 7, Linux OS |
Dimensions and weight |
| Width | 250 mm |
| Height | 57 mm |
| Depth | 154 mm |
Operating Conditions |
| Operating Temperature | -40...70 °C |
| Vibration | 5 Grms. 5 Hz to 500 Hz. 1 hr/axis |
| Shock | 50 g/11ms ±X. ±Y. ±Z. 3 shocks each axis |
Standards and Certifications |
| EMI | FCC Part 15 Subpart B Class A, CISPR 22 Class |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-6-2, EN 61000-6-4 |
| Safety | UL 60950-1, UL 508, EN 60950-1, CSA C22.2 No. 60950-1-03 |
