Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall |
| Protection Level of Chassis | IP20 |
| Type | Fanless |
CPU |
| Processor Installed | Intel Celeron 3965U |
| Max CPU frequency | 2.2 GHz |
Memory |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic |
| Graphic Controller | Intel HD Graphics 620 |
Ethernet |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces |
| COM Total | 4 |
| RS-232/422/485 | 4 |
| USB Total | 4 |
| USB v3.x | 4 |
Digital Input |
| Isolation DIO | Yes |
Drive interfaces |
| mSATA | 1 |
Storage Cage |
| Number Of Cage External | 2 |
| 2.5" Cage Intenal | 2 |
Extension Slots |
| Mini-PCIe/Mini Card | 1 |
Connectors |
| Connectors | 4xDB9, DB15 VGA, HDMI, 3xUSB, Line In, Line Out, 2xM12 |
System Power Input |
| Input Voltage DC | 24...110 V |
| Power Consumption | 70 W |
Software |
| Operating System Compatibility | Linux OS, Windows IoT Enterprise 10 |
Dimensions and weight |
| Width | 250 mm |
| Height | 75 mm |
| Depth | 150 mm |
Operating Conditions |
| Operating Temperature | -40...70 °C |
Standards and Certifications |
| EMI | FCC Part 15 Subpart B Class A, CISPR 32 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 55032, EN 55035 |
| Rolling Stock | EN 50121-4, EN 50155, EN 50121-3-2, EN 45545-2 |
| Safety | EN 62368-1 (LVD), UL 62368-1, IEC 62368-1 |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-64, IEC 61373 |
