System Architecture | |
| Form Factor | 3.5" |
CPU | |
| CPU Support Type | Vortex86 |
| Processor Installed | Vortex86DX |
| Max CPU frequency | 0.8 GHz |
Chipset | |
| Chipset | Vortex86 System-on-Chip |
Memory | |
| Form-factor | DDR2 |
| Default on Board Memory | 0.25 GB |
| Maximum Memory | 0.5 GB |
| Assembly | Fixed on Board |
Graphic | |
| Interfaces | LVDS, LCD, VGA |
Ethernet | |
| Controller Type | Integrated with Chipset, Realtek RTL8100B 10/100 Base-TX |
| Total Ethernet | 3 |
| 10/100 Mbit/s | 3 |
Interfaces | |
| COM Total | 4 |
| USB Total | 3 |
| USB 2.0 | 3 |
Drive interfaces | |
| CompactFlash Slots | 1 |
Extension Slots | |
| Total | 2 |
| Mini-PCI | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB9, DB15 VGA, RJ45 Ethernet |
Software | |
| Operating System Compatibility | Windows Embedded Standard 2009, Windows CE 6.0, Windows 98, Linux OS, Windows CE 5.0, POSReady, FreeBSD, Vxworks |
Dimensions and weight | |
| Width | 102 mm |
| Length | 146 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
