System Architecture | |
| Form Factor | PC/104 |
Construction | |
| Type | Fanless |
CPU | |
| CPU Support Type | Vortex86 |
| Processor Installed | Vortex86DX2 |
| Max CPU frequency | 0.8 GHz |
Chipset | |
| Chipset | Vortex86 System-on-Chip |
Memory | |
| Form-factor | DDR2 |
| Default on Board Memory | 0.5 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in Chipset |
| Interfaces | LVDS, LCD, VGA |
Ethernet | |
| Controller Type | Integrated with Chipset |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
Interfaces | |
| COM Total | 4 |
| RS-232/485 | 4 |
| USB Total | 2 |
| USB 2.0 | 2 |
| LPT | LPT |
Audio | |
| Audio Controller | Realtek ALC262 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 26-pin LPT, 4x10-pin RS-232, 10-pin USB 2.0, 16-pin LVDS, 44-pin LCD, 6-pin JTAG, 4-pin Power, 20-pin GPIO, 2-pin Reset, 4-pin Mic-in, 5-pin KB, 5-pin MS, 10-pin VGA, 4-pin Line-out, 8-pin Ethernet, SATA, 4-pin Touch Screen |
Software | |
| Operating System Compatibility | MS DOS, Windows CE 6.0, Windows XP, Windows XP Embedded, Linux OS, FreeBSD, POSReady, Windows CE 7.0, Vxworks, X-LINUX, QNX |
Dimensions and weight | |
| Width | 96 mm |
| Length | 90 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
