System Architecture | |
| Form Factor | PC/104 |
Construction | |
| Type | Fanless |
CPU | |
| CPU Support Type | Vortex86 |
| Processor Installed | Vortex86DX2 |
| Max CPU frequency | 0.8 GHz |
Memory | |
| Form-factor | DDR2 |
| Default on Board Memory | 0.5 GB |
| Assembly | Fixed on Board |
Graphic | |
| Interfaces | VGA, LVDS |
Ethernet | |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
Interfaces | |
| COM Total | 4 |
| RS-232/485 | 4 |
| USB Total | 2 |
| USB 2.0 | 2 |
| LPT | LPT |
Digital Input-Output | |
| Channels of DIO | 16 |
Audio | |
| Audio Controller | Realtek ALC888S |
Drive interfaces | |
| SATA 2 | 1 |
Extension Slots | |
| PC/104 | 1 |
Connectors | |
| Internal Ports | SATA 2, 26-pin LPT, 20-pin GPIO, 16-pin LVDS, 10-pin VGA, 10-pin USB 2.0, 4x10-pin RS-232, 8-pin Ethernet, 5-pin KB, 5-pin MS |
Dimensions and weight | |
| Width | 90 mm |
| Length | 96 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
