System Architecture | |
| Form Factor | PC/104 |
CPU | |
| CPU Support Type | Vortex86 |
| Processor Installed | Vortex86DX3 |
| Max CPU frequency | 1 GHz |
Memory | |
| Form-factor | DDR3 |
| Default on Board Memory | 1 GB |
| Assembly | Fixed on Board |
Graphic | |
| Interfaces | LVDS, VGA |
Ethernet | |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
Interfaces | |
| COM Total | 3 |
| RS-232/485 | 3 |
| USB Total | 2 |
| USB 2.0 | 2 |
Audio | |
| Audio Controller | Realtek ALC262 |
Connectors | |
| Connectors | 3xDB9, DB15 VGA, LVDS, RJ45, 2xUSB |
Dimensions and weight | |
| Width | 96 mm |
| Length | 90 mm |
Operating Conditions | |
| Operating Temperature | -10...60 °C |
