Ethernet | |
| Total Ethernet | 5 |
| 10/100/1000 Mbit/s | 5 |
| Type 10/100/1000 Mbit/s | RJ-45 |
Switch Properties | |
| Managed | No |
Supported Protocols | |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), EE 802.3af for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control |
LED / Controls | |
| Setup of Operation Mode | By Switches |
System Power Input | |
| Input Voltage DC | 9...36 V |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
Dimensions and weight | |
| Width | 167 mm |
| Depth | 139.6 mm |
| Height | 58.8 mm |
Operating Conditions | |
| Operating Temperature | -30...70 °C |
| Vibration | 1g |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock |
| Vehicle | E-Mark |
