System Architecture | |
| Form Factor | System on Module (SoM) |
Construction | |
| Type | Fanless |
CPU | |
| CPU Support Type | Vortex86 |
| Processor Installed | Vortex86EX |
| Max CPU frequency | 0.4 GHz |
Chipset | |
| Chipset | Vortex86 System-on-Chip |
Memory | |
| Form-factor | DDR3 |
| Default on Board Memory | 0.5 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Integrated with Chipset |
| 10/100 Mbit/s | 1 |
Interfaces | |
| USB Total | 2 |
| USB 2.0 | 2 |
Digital Input-Output | |
| Channels of DIO | 80 |
Extension Slots | |
| PCI Express x1 | 1 |
Additional Functions | |
| Watchdog timer type | Hardware |
Software | |
| Operating System Compatibility | MS DOS, Windows CE 5.0, Windows CE 6.0, Windows Embedded Compact 7, Windows XP, Windows XP Embedded, Linux OS, QNX 6, FreeBSD, Vxworks |
Dimensions and weight | |
| Width | 28 mm |
| Length | 45 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
