System Architecture | |
| Form Factor | 3.5" |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Vortex86EX2 |
| Max CPU frequency | 0.6 GHz |
Memory | |
| Form-factor | DDR3 |
| Default on Board Memory | 1 GB |
| Assembly | Fixed on Board |
Ethernet | |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
Interfaces | |
| COM Total | 5 |
| RS-232 | 3 |
| RS-232/485 | 2 |
| USB Total | 4 |
| USB 2.0 | 4 |
Audio | |
| Audio Controller | Realtek ALC262 |
Drive interfaces | |
| MicroSD | 1 |
| SD Slots | 1 |
Extension Slots | |
| Mini-PCIe/Mini Card | 2 |
Additional Functions | |
| Watchdog timer type | Hardware |
Connectors | |
| Connectors | 5xDB9, LVDS, RJ45, 4xUSB, Mic In, Line In, Line Out, DB15 CAN Bus |
Software | |
| Operating System Compatibility | MS DOS, Windows CE 6.0, Windows Embedded Compact 7, Linux OS, QNX |
Dimensions and weight | |
| Width | 102 mm |
| Length | 146 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
