Construction | |
| Construction Chassis | Heavy-Duty Steel Chassis |
| Mounting Configuration | Wall VESA 100 |
| Protection Level of Chassis | IP69K |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15 " |
| Maximum resolution | 1024x768 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 350 Cd/m2 |
| Contrast Ratio | 700~1 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | Intel Atom E3845 |
| Max CPU frequency | 1.91 GHz |
Chipset | |
| Chipset | Intel Atom SoC |
Memory | |
| Form-factor | DDR3L |
| ECC | No |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 2 |
Installed drive | |
| Drive Type | SSD |
| 1st Storage Capacity | 120 GB |
LED / Controls | |
| LED | 1xHDD LED, 1xOn/Off LED |
Connectors | |
| Connectors | 2xDB9, 2xRJ45 Ethernet, 2xUSB |
System Power Input | |
| Input Voltage AC | 90...264 V |
| Power Consumption | 50 W |
Software | |
| Operating System Compatibility | Windows 7, Linux OS, Windows 8.1 |
Dimensions and weight | |
| Width | 385.5 mm |
| Height | 455 mm |
| Depth | 94 mm |
Operating Conditions | |
| Operating Temperature | 0...35 °C |
Standards and Certifications | |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8 |
| Safety | EN 60950-1 |
