Construction | |
| Construction Chassis | Rubber |
| Protection Level of Front Side (Panel) | IP66 |
| Protection Level of Chassis | IP66 |
| Type | Fanless |
Display | |
| Diagonal | 10.4 " |
| Maximum resolution | 1024x768 Dots |
| Brightness | 1000 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | Intel Atom E3827 |
| Max CPU frequency | 1.75 GHz |
Memory | |
| Form-factor | DDR3L |
| ECC | No |
| Default on Board Memory | 4 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n/ac |
Interfaces | |
| COM Total | 3 |
| RS-232 | 3 |
| USB Total | 2 |
Industrial Interfaces | |
| CAN Port | 1 |
Drive interfaces | |
| SD Slots | 1 |
Antenna characteristics | |
| Bluetooth | Yes |
Connectors | |
| Connectors | 3xDB9, 2xRJ45, 2xUSB, DC Input |
System Power Input | |
| Input Voltage DC | 18...60 V |
Battery | |
| Battery Capacity | 3000 mA*h |
Software | |
| Operating System Installed | Windows 8.1 |
Dimensions and weight | |
| Width | 276 mm |
| Height | 252 mm |
| Depth | 67.3 mm |
Operating Conditions | |
| Operating Temperature | -30...55 °C |
| Shock | 40G.11ms terminal sawtooth |
Standards and Certifications | |
| Certifications | CE, FCC |
