Construction | |
| Construction Chassis | Rubber, Plastic Chassis with Aluminum Heatsink |
| Mounting Configuration | Wall VESA 75 |
| Protection Level of Chassis | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 8 " |
| Maximum resolution | 1280x720 Dots |
| Brightness | 1000 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | NXP i.MX6 quad-core |
| Socket | CPU onboard |
| Max CPU frequency | 1.3 GHz |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 3 |
| RS-232 | 2 |
| RS-232/422/485 | 1 |
| USB Total | 3 |
| USB 2.0 | 2 |
| USB v3.x | 1 |
Drive interfaces | |
| MicroSDHC | 1 |
Extension Slots | |
| M.2 | 2 |
| SIM Card slots | 2, Nano SIM |
Additional Functions | |
| GPS | GPS |
LED / Controls | |
| LED | 1xHDD LED, Battеry Status, 1xOn/Off LED, WLAN LED, WWAN LED |
| Controls | On/Off, Function Keys, Volume Keys |
Connectors | |
| Connectors | 3xDB9, 3xUSB, 2x8-pin M12 USB, M12 LAN |
System Power Input | |
| Input Voltage DC | 9...60 V |
Software | |
| Operating System Compatibility | Windows 10, Linux kernel 4.x |
Dimensions and weight | |
| Width | 250 mm |
| Height | 179 mm |
| Depth | 67.5 mm |
Operating Conditions | |
| Operating Temperature | -30...60 °C |
| Vibration | Vibration (random) - 2g@5~500 Hz (in operation) Vibration - Operating: MIL-STD-810G. 514.6 Procedure 1.Category 4 - Storage: MIL-STD-810G. 514.6 Procedure 1. Category 24 |
| Shock | Shock - Operating: MIL-STD-810G. Method 516.6. Procedure I. trucks and semi-trailers = 40g - Crash hazard: MIL-STD-810G. Method 516.6. Procedure V. ground equipment = 75g |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
