Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Panel, Wall, Wall VESA 100, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP65 |
| Type | Fanless |
Display |
| Display Type | LCD TFT |
| Diagonal | 10.4 " |
| Maximum resolution | 1024x768 Dots |
| Brightness | 1000 Cd/m2 |
| Contrast Ratio | 600~1 |
Touch Screen |
| Touch Screen Type | Resistive |
CPU |
| Processor Installed | Intel Core i7-2610UE |
| Max CPU frequency | 2.4 GHz |
Chipset |
| Chipset | Intel QM67 |
Memory |
| Form-factor | DDR3 |
| Socket Type | 1xSODIMM |
| Default on Board Memory | 2 GB |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic |
| Graphic Controller | Integrated in CPU |
Ethernet |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 2 |
| USB 2.0 | 2 |
Drive interfaces |
| CFast Slots | 1 |
Extension Slots |
| Total | 2 |
| Mini-PCIe/Mini Card | 2 |
LED / Controls |
| LED | Power LED |
| Controls | On/Off, Control Buttons, Function Keys |
Connectors |
| Connectors | 2xDB9, RJ45, 2xUSB, Mic In, Line Out, DC input (terminal block), DB9 GPIO, SMBus Power Output |
System Power Input |
| Input Voltage DC | 9...36 V |
| Power Consumption | 32 W |
Power Supply |
| Supported Types of Power Supply | External power adapter AC/DC |
Software |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Standard 2009 |
Dimensions and weight |
| Width | 290 mm |
| Height | 230 mm |
| Depth | 68 mm |
Operating Conditions |
| Operating Temperature | -30...60 °C |
| Vibration | Vibration (random): 2g @5~500Hz; Vibration Operating: MIL-STD-810G. 514.6 Procedure 1. Category 4; Storage vibration: MIL-STD-810G. 514.6 Procedure 1. Category 24 |
| Shock | Shock Operating: MIL-STD-810G. Method 516.6. Procedure I. trucks and semi-trailers= 20g; Crash hazard: MIL-STD-810G. Method 516.6. Procedure V. ground equipment= 75g |
Standards and Certifications |
| Certifications | CE, FCC Class B |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock |
