Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Panel, Wall, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP54 |
| Material Front Side (Panel) | ABS plastic |
Display | |
| Display Type | LCD TFT |
| Diagonal | 7 " |
| Maximum resolution | 640x480 Dots |
| Brightness | 500 Cd/m2 |
| Contrast Ratio | 600~1 |
Touch Screen | |
| Touch Screen Type | Resistive |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off, Control Buttons |
Additional Functions | |
| Camera Frontside | 2 MP |
Connectors | |
| Connectors | DB15 VGA, LVDS, 1xUSB, Mic In, Line Out, SD/MMC/MS Card Reader |
System Power Input | |
| Input Voltage DC | 9...36 V |
| Power Consumption | 18 W |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
| Vibration | Random: 5g. 5~500 Hz |
| Shock | Operating: MIL-STD-810F. Method 516.5. Procedure I. Trucks and semi-trailers= 20g |
Dimensions and weight | |
| Width | 182 mm |
| Height | 138 mm |
| Depth | 36.3 mm |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
