System Architecture | |
| Form Factor | PC/104 |
Construction | |
| Type | Fanless |
CPU | |
| CPU Support Type | Vortex86 |
| Processor Installed | Vortex86MX+ |
| Max CPU frequency | 0.8 GHz |
Chipset | |
| Chipset | Vortex86 System-on-Chip |
Memory | |
| Form-factor | DDR2 |
| Default on Board Memory | 1 GB |
| Maximum Memory | 1 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | LVDS, LCD, VGA |
Ethernet | |
| Controller Type | Integrated with Chipset |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
Interfaces | |
| COM Total | 3 |
| RS-232 | 2 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB 2.0 | 4 |
| LPT | LPT |
Audio | |
| Audio Controller | Realtek ALC262 |
Drive interfaces | |
| CompactFlash Slots | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 26-pin LPT, 2x10-pin RS-232, 16-pin LVDS, 44-pin LCD, 20-pin GPIO, 2-pin Reset, 4-pin Mic-in, 10-pin RS-232/422/485, 5-pin KB, 5-pin MS, 10-pin VGA, 2x10-pin USB, 2-pin DC-In Power, 4-pin Line-out, 8-pin Ethernet |
Dimensions and weight | |
| Width | 96 mm |
| Length | 90 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
