Construction | |
| Construction Chassis | Open Frame |
| Mounting Configuration | Built-in, Panel |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 6.4 " |
| Maximum resolution | 640x480 Dots |
| Aspect Ratio | 4:3 |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 300~1 |
CPU | |
| Processor Installed | Vortex86DX |
| Max CPU frequency | 0.8 GHz |
Memory | |
| Form-factor | DDR2 |
| Default on Board Memory | 0.25 GB |
LED / Controls | |
| Controls | On/Off |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB15 VGA, PS/2 Keyboard, Audio, AC Input |
System Power Input | |
| Input Voltage DC | 5...5 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 15 W |
Dimensions and weight | |
| Width | 160 mm |
| Height | 122 mm |
| Depth | 25.5 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
