Construction | |
| Construction Chassis | Open Frame |
| Mounting Configuration | Built-in, Panel |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 6.5 " |
| Maximum resolution | 640x480 Dots |
| Aspect Ratio | 4:3 |
| Brightness | 800 Cd/m2 |
| Contrast Ratio | 600~1 |
CPU | |
| Processor Installed | Vortex86DX2 |
| Socket | CPU onboard |
| Max CPU frequency | 0.8 GHz |
Chipset | |
| Chipset | Vortex86 System-on-Chip |
Memory | |
| Form-factor | DDR2 |
| Socket Type | Soldered |
| Default on Board Memory | 0.5 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in Chipset |
Ethernet | |
| Controller Type | Realtek 8111F |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232/485 | 4 |
| USB Total | 4 |
| USB 2.0 | 4 |
Audio | |
| Audio Controller | Realtek ALC262 |
Extension Slots | |
| Total | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB9, DB15 VGA, PS/2 Keyboard/Mouse, RJ45 Ethernet, 1xUSB, DC Input |
System Power Input | |
| Input Voltage DC | 5...12 V |
| Power Consumption | 47 W |
Software | |
| Operating System Compatibility | MS DOS, Windows XP, Windows 7, Linux OS, Windows Embedded CE |
Dimensions and weight | |
| Width | 190 mm |
| Height | 145 mm |
| Depth | 41.9 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
