Construction | |
| Construction Chassis | Open Frame |
| Mounting Configuration | Built-in, Panel |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 10.4 " |
| Maximum resolution | 800x600 Dots |
| Aspect Ratio | 4:3 |
| Brightness | 400 Cd/m2 |
| Contrast Ratio | 500~1 |
CPU | |
| Processor Installed | Vortex86DX |
| Max CPU frequency | 0.8 GHz |
Memory | |
| Form-factor | DDR2 |
| Default on Board Memory | 0.5 GB |
Ethernet | |
| Total Ethernet | 1 |
Interfaces | |
| COM Total | 1 |
| RS-485 | 1 |
| USB Total | 1 |
| USB 2.0 | 1 |
Drive interfaces | |
| CompactFlash Slots | 1 |
LED / Controls | |
| Controls | On/Off |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB9, DB15 VGA, PS/2 Keyboard/Mouse, RJ45 Ethernet, 1xUSB, AC Input |
System Power Input | |
| Input Voltage DC | 5...5 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 47 W |
Dimensions and weight | |
| Width | 303 mm |
| Height | 204 mm |
| Depth | 21 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
