Display | |
| Diagonal | 15 " |
| Maximum resolution | 1024x768 Dots |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 700~1 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | Vortex86MX+ |
Memory | |
| Form-factor | DDR2 |
| Default on Board Memory | 0.5 GB |
| Maximum Memory | 1 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232/422/485 | 6 |
| USB Total | 2 |
| USB 2.0 | 2 |
Drive interfaces | |
| CompactFlash Slots | 1 |
Connectors | |
| Connectors | 6xDB9, 2xRJ45, 2xUSB |
System Power Input | |
| Input Voltage DC | 5...12 V |
Dimensions and weight | |
| Width | 368 mm |
| Height | 278 mm |
| Depth | 45.5 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
