Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Panel |
Display | |
| Display Type | LCD TFT |
| Diagonal | 5.7 " |
| Maximum resolution | 640x480 Dots |
CPU | |
| Processor Installed | ARM Cortex A8 TI AM335X |
| Max CPU frequency | 1 GHz |
Memory | |
| Default on Board Memory | 0.5 GB |
| SRAM | 128 kB |
Installed drive | |
| Flash Memory Capacity | 256 MB |
| EEPROM Memory Capacity | 16 kB |
Drive interfaces | |
| MicroSD | 1 |
| MicroSDHC | 1 |
Expansion Module | |
| Quantity of Slots | 3 |
| Supported Module | I-8K series, I-87K series |
Software | |
| Operating System Installed | Windows CE 7.0 |
| Programming Method | C/C++ |
| Development Software | Visual Studio .NET |
Ethernet | |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-485 | 1 |
| USB Total | 2 |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
Dimensions and weight | |
| Width | 182 mm |
| Depth | 158 mm |
| Height | 125 mm |
System Power Input | |
| Input Voltage DC | 10...30 V |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
